Automate Pipeline Pigging with Multiple Launches

The Argus Multi-Pig Launcher is a vertically aligned Pig Valve that enables operators to store and launch up to eleven (11) pigs. Once loaded, each pig can be automatically launched remotely without further human intervention, resulting in lower operation costs and emissions. It offers a practical solution for maintaining remote lines or lines requiring high-frequency pigging.

  • Clear out wax, blockages, and Black powder.
  • Mitigate corrosion.
  • Automate Operations.
  • Optimize Revenue by Reducing OpEx.
  • Drop GHG Emissions by 97%

The Argus Multi-Pig Launcher can be used in both liquid and gas applications. It is ideal for remote well sites, sites requiring frequent pigging, offshore production platforms, and where reducing emissions is required or of interest.

Companies Needing to Reduce Emissions:
The Argus Multi-Pig Launcher is the perfect solution for companies aiming to decrease GHG emissions, making them an environmentally friendly choice.

  • Less venting per pig launch reduces GHG emissions by up to 97%.
  • Ask us about our MPL Cost & Emissions Calculator to find out how much you’ll save using an Argus Multi-Pig Launcher vs. a traditional Pig Barrel.

Situations Requiring High-Frequency Pigging:
Certain media or locations require high-frequency pigging. The Argus Multi-Pig Launcher’s vertical barrel and increases how many pigs can be launched per load.

  • Remote Operability.
  • One trip for 11 launches.
  • Reduces and prevents the formation of hydrates by keeping moisture content at lower levels.

Ideal for Hard-to-Reach, Remote Locations:
A great choice for offshore applications and areas with rugged terrain.

  • Small footprint compared to a traditional Pig Barrel.
  • Compact and lightweight design.
  • Less travel for operators between pig loading.

Reduce OpEx While Maintaining Pipeline Integrity:

  • Lower labor costs.
  • Automated operations.
  • Reduced travel expenses.

Argus Multi-Pig Launchers are API and ISO certified, backed by 65 years of consistent quality and reliability with time-tested designs.

Quality and Durable

Full-Circle Support

  • Maintenance and repair services.
  • Engineering services.
  • Product-use training and educational services.
  • Field evaluations.

Proven and Trusted

  • Over 40,000 valves supplied.
  • Trusted by over 380 companies worldwide.

Argus Multi-Pig Launchers are available with the following specifications:

Size Range: 2” – 20” (DN 50 to DN500)

Temperature Range: -50°F to +250°F (-46°C to +121°C)

Pressure Range: 150 to 1500 ASME Class

End Connections:

  • Raised Face (RF)
  • Ring Joint (RTJ)

Operation/Actuation Options:

  • Manually operated
  • On-site electric power supply
  • Self-contained solar
  • Pneumatic

DBB Packages:

Contact us for a quote!
